WXD3-13 1k ohm Multi-turn Wire-wound Potentiometer

WXD3-13 1k ohm Multi-turn Wire-wound Potentiometer in Bangladesh

These are suitable to use for electronic devices where you need high precision such as Adjust Timer, Speed, Temperature, etc. CityTechBD

• Brand Name: BOCHEN/XINGHOU
• Model Number: WXD3-13
• Type: Rotary Potentiometer
• Technology: Wirewound
• Resistance: 1 kOhm
• Resistance Tolerance: ±5%
• Rated Power: 2W
• Max. Operating Voltage: 160V
• Operating Temperature: -55°C~+125°C
• Effective Travel: More than 1800°±10°
• Insulation Resistance: More than 1G ohm
• Noise: Less than 3%R or 3 ohm
• Terminal Resistance: Less than 0.2%R or 5 ohm
• Independent Linearity: ±0.3%
• Body Size: 26.5 x 20mm / 1" x 0.8" (L * D)
• Screw Thread Dia.: 8mm / 0.3"
• Shaft Diameter: 4mm / 0.16"
• Shaft Length: 12mm / 0.5"
• Total Length: 48mm / 1.9"

Note: Product Images are shown for illustrative purposes only and may differ from the actual product. CityTechBD

Package Includes:

1 x WXD3-13 1k ohm Multi-turn Wire-wound Potentiometer CityTechBD
