Photoelectric sensors work by converting changes in light intensity into changes in electrical signals to achieve control. A photoelectric switch is a small electronic device that detects changes in the intensity of the light it receives. Photoelectric sensor is usually composed of three parts, they are transmitter, receiver and detection circuit. CityTech BD
SMT automatic film production process, better consistency Strict process management All processes are in strict accordance with the standard documents to implement the ISO9001 management measures. CityTech BD
Product Images are shown for illustrative purposes only and may differ from the actual product. CityTech BD

CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD
Applications:
- Packaging
- Positioning
- Quality Assurance
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- EASY TO INSTALL CYLINDRICAL
- SHORT CIRCUIT PROTECTION. REVERSE POLARITY PROTECTION
- LONG DISTANCE LENS
- STRONGE COPPER
CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD
General Specification |
Model | CDD-11N |
Type | Reflective photoelectric sensor diffuse type. |
Dimensions | 69 L x 18 D mm. |
Sensing distance | 11 (cm). |
Operating temperature | -25 to 55 degrees C. |
Operating Voltage | 10-30 VDC (including ripple 10%). |
Light source | Infrared. |
Output | NPN open drain, 100mA / 30VDC. |
Response Time | 1.5 (ms). |
Lag phase | 10% Max. |
Shipment Weight | 0.065 kg |
Shipment Dimensions | 11 × 11 × 5 cm |
Please allow 5% measuring deviation due to manual measurement.
CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD
Documentation:



CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD CityTech BD
Package Includes:
1 x Photoelectric Sensor CDD-11N Diffuse NPN Infrared Metal Body NO+NC
